Event ID: mw
Origin ID: 001
Date:
Filename: gmtmap.jpg
Solution Name: T050.0sec_Z008.0km_
Event ID: mw
Origin ID: 001
Date:
Seismic Moment Tensor Solution
2007/01/24 (024) 12:05:50.00 37.4191 -117.0902 1012422
Depth = 8.0 (km)
Mw = 3.09
Mo = 5.43x10^20 (dyne x cm)
Percent Double Couple = 82 %
Percent CLVD = 18 %
no ISO calculated
Epsilon=-0.09
Percent Variance Reduction = 3.43 %
Total Fit = 0.18
Major Double Couple
strike dip rake
Nodal Plane 1: 25 38 -22
Nodal Plane 2: 132 76 -126
DEVIATORIC MOMENT TENSOR
Moment Tensor Elements: Spherical Coordinates
Mrr= -2.00 Mtt= -2.05 Mff= 4.05
Mrt= -3.09 Mrf= 2.30 Mtf= -1.52 EXP=20
Moment Tensor Elements: Cartesian Coordinates
-2.05 1.52 -3.09
1.52 4.05 -2.30
-3.09 -2.30 -2.00
Eigenvalues:
T-axis eigenvalue= 5.67
N-axis eigenvalue= -0.52
P-axis eigenvalue= -5.15
Eigenvalues and eigenvectors of the Major Double Couple:
T-axis ev= 5.67 trend=249 plunge=23
N-axis ev= 0.00 trend=142 plunge=35
P-axis ev=-5.67 trend=6 plunge=46
Maximum Azmuithal Gap=107 Distance to Nearest Station= 91.2 (km)
Number of Stations (D=Displacement/V=Velocity) Used=4 (defining only)
R09A.TA.D S08C.TA.D FUR.CI.D S11A.TA.D
-----------------
---------------------####
------------ ----------####
#------------- P -----------#####
###------------ ------------######
#####---------------------------######
-#######--------------------------#######
#########-------------------------#######
############------------------------#######
#############-----------------------#######
###############--------------------#########
#################------------------#########
###################----------------#########
####################--------------##########
#####################----------##########
T #######################--------##########
#########################-----##########
########################################
#######################################
#########################----#######
######################----------#
##################-----------
############------------
-----------------
All Stations defining and nondefining:
Station.Net Def Distance Azi Bazi lo-f hi-f vmodel
(km) (deg) (deg) (Hz) (Hz)
R09A.TA (D) Y 91.2 1 181 0.030 0.100 R09A.TA.wus.glib
S08C.TA (D) Y 95.7 276 95 0.030 0.100 S08C.TA.wus.glib
FUR.CI (D) Y 107.4 169 349 0.030 0.100 FUR.CI.wus.glib
S11A.TA (D) Y 120.6 78 259 0.030 0.100 S11A.TA.wus.glib
(V)-velocity (D)-Displacement
Author: www-data
Date: 2015/11/18 23:01:41
mtinv Version 2.1_DEVEL OCT2008
Solution Name: T051.0sec_Z016.0km_
Event ID: mw
Origin ID: 001
Date:
Seismic Moment Tensor Solution
2007/01/24 (024) 12:05:51.00 37.4191 -117.0902 1012422
Depth = 16.0 (km)
Mw = 3.17
Mo = 7.14x10^20 (dyne x cm)
Percent Double Couple = 99 %
Percent CLVD = 1 %
no ISO calculated
Epsilon=0.00
Percent Variance Reduction = 9.40 %
Total Fit = 4.93
Major Double Couple
strike dip rake
Nodal Plane 1: 67 61 -20
Nodal Plane 2: 167 72 -150
DEVIATORIC MOMENT TENSOR
Moment Tensor Elements: Spherical Coordinates
Mrr= -2.09 Mtt= -2.42 Mff= 4.51
Mrt= -2.50 Mrf= 2.46 Mtf= 4.83 EXP=20
Moment Tensor Elements: Cartesian Coordinates
-2.42 -4.83 -2.50
-4.83 4.51 -2.46
-2.50 -2.46 -2.09
Eigenvalues:
T-axis eigenvalue= 7.12
N-axis eigenvalue= 0.03
P-axis eigenvalue= -7.15
Eigenvalues and eigenvectors of the Major Double Couple:
T-axis ev= 7.12 trend=295 plunge=7
N-axis ev= 0.00 trend=195 plunge=55
P-axis ev=-7.12 trend=30 plunge=34
Maximum Azmuithal Gap=107 Distance to Nearest Station= 91.2 (km)
Number of Stations (D=Displacement/V=Velocity) Used=4 (defining only)
R09A.TA.D S08C.TA.D FUR.CI.D S11A.TA.D
####-------------
########-----------------
#########---------- -------
###########---------- P ---------
############---------- ----------
#############------------------------
T ##############--------------------------
##############-------------------------#
################------------------------###
#################----------------------####
#################--------------------#######
#################------------------#########
##################---------------###########
##################-------------#############
###################---------###############
###################-----###################
#########################################
-#######################################
------------------#####################
----------------####################
----------------#################
----------------#############
---------------##########
------------######
All Stations defining and nondefining:
Station.Net Def Distance Azi Bazi lo-f hi-f vmodel
(km) (deg) (deg) (Hz) (Hz)
R09A.TA (D) Y 91.2 1 181 0.030 0.100 R09A.TA.wus.glib
S08C.TA (D) Y 95.7 276 95 0.030 0.100 S08C.TA.wus.glib
FUR.CI (D) Y 107.4 169 349 0.030 0.100 FUR.CI.wus.glib
S11A.TA (D) Y 120.6 78 259 0.030 0.100 S11A.TA.wus.glib
(V)-velocity (D)-Displacement
Author: www-data
Date: 2015/11/18 23:01:41
mtinv Version 2.1_DEVEL OCT2008
Solution Name: T052.0sec_Z012.0km_
Event ID: mw
Origin ID: 001
Date:
Seismic Moment Tensor Solution
2007/01/24 (024) 12:05:52.00 37.4191 -117.0902 1012422
Depth = 12.0 (km)
Mw = 3.28
Mo = 1.03x10^21 (dyne x cm)
Percent Double Couple = 92 %
Percent CLVD = 8 %
no ISO calculated
Epsilon=0.04
Percent Variance Reduction = 30.71 %
Total Fit = 3.58
Major Double Couple
strike dip rake
Nodal Plane 1: 82 77 -9
Nodal Plane 2: 174 81 -167
DEVIATORIC MOMENT TENSOR
Moment Tensor Elements: Spherical Coordinates
Mrr= -0.04 Mtt= -0.23 Mff= 0.27
Mrt= -0.20 Mrf= 0.21 Mtf= 0.96 EXP=21
Moment Tensor Elements: Cartesian Coordinates
-0.23 -0.96 -0.20
-0.96 0.27 -0.21
-0.20 -0.21 -0.04
Eigenvalues:
T-axis eigenvalue= 1.01
N-axis eigenvalue= 0.04
P-axis eigenvalue= -1.05
Eigenvalues and eigenvectors of the Major Double Couple:
T-axis ev= 1.01 trend=307 plunge=2
N-axis ev= 0.00 trend=208 plunge=74
P-axis ev=-1.01 trend=38 plunge=16
Maximum Azmuithal Gap=107 Distance to Nearest Station= 91.2 (km)
Number of Stations (D=Displacement/V=Velocity) Used=4 (defining only)
R09A.TA.D S08C.TA.D FUR.CI.D S11A.TA.D
#######----------
##########-------------
############------------- P -
##############------------- ---
T ###############--------------------
###############---------------------
-#################-----------------------
##################-----------------------
###################------------------------
###################------------------------
###################----------------------###
####################-----------------#######
####################----------##############
############################################
--#########################################
-------------------########################
-------------------######################
------------------######################
------------------#####################
-----------------###################
----------------#################
---------------##############
-------------############
----------########
All Stations defining and nondefining:
Station.Net Def Distance Azi Bazi lo-f hi-f vmodel
(km) (deg) (deg) (Hz) (Hz)
R09A.TA (D) Y 91.2 1 181 0.030 0.100 R09A.TA.wus.glib
S08C.TA (D) Y 95.7 276 95 0.030 0.100 S08C.TA.wus.glib
FUR.CI (D) Y 107.4 169 349 0.030 0.100 FUR.CI.wus.glib
S11A.TA (D) Y 120.6 78 259 0.030 0.100 S11A.TA.wus.glib
(V)-velocity (D)-Displacement
Author: www-data
Date: 2015/11/18 23:01:41
mtinv Version 2.1_DEVEL OCT2008
Solution Name: T053.0sec_Z004.0km_
Event ID: mw
Origin ID: 001
Date:
Seismic Moment Tensor Solution
2007/01/24 (024) 12:05:53.00 37.4191 -117.0902 1012422
Depth = 4.0 (km)
Mw = 3.27
Mo = 9.87x10^20 (dyne x cm)
Percent Double Couple = 96 %
Percent CLVD = 4 %
no ISO calculated
Epsilon=0.02
Percent Variance Reduction = 51.66 %
Total Fit = 10.33
Major Double Couple
strike dip rake
Nodal Plane 1: 176 83 -177
Nodal Plane 2: 86 87 -7
DEVIATORIC MOMENT TENSOR
Moment Tensor Elements: Spherical Coordinates
Mrr= 0.06 Mtt= -1.41 Mff= 1.35
Mrt= -1.27 Mrf= 0.46 Mtf= 9.68 EXP=20
Moment Tensor Elements: Cartesian Coordinates
-1.41 -9.68 -1.27
-9.68 1.35 -0.46
-1.27 -0.46 0.06
Eigenvalues:
T-axis eigenvalue= 9.77
N-axis eigenvalue= 0.20
P-axis eigenvalue= -9.97
Eigenvalues and eigenvectors of the Major Double Couple:
T-axis ev= 9.77 trend=131 plunge=3
N-axis ev= 0.00 trend=243 plunge=82
P-axis ev=-9.77 trend=41 plunge=7
Maximum Azmuithal Gap=107 Distance to Nearest Station= 91.2 (km)
Number of Stations (D=Displacement/V=Velocity) Used=4 (defining only)
R09A.TA.D S08C.TA.D FUR.CI.D S11A.TA.D
########---------
###########------------
#############------------ P -
###############------------ ---
################-------------------
#################--------------------
-##################----------------------
###################----------------------
####################-----------------------
####################-----------------------
####################-----------------------
####################-------------###########
############################################
-------------------#########################
--------------------#######################
--------------------#######################
-------------------######################
------------------######################
------------------############### ###
-----------------############## T ##
----------------##############
--------------###############
-------------############
---------#########
All Stations defining and nondefining:
Station.Net Def Distance Azi Bazi lo-f hi-f vmodel
(km) (deg) (deg) (Hz) (Hz)
R09A.TA (D) Y 91.2 1 181 0.030 0.100 R09A.TA.wus.glib
S08C.TA (D) Y 95.7 276 95 0.030 0.100 S08C.TA.wus.glib
FUR.CI (D) Y 107.4 169 349 0.030 0.100 FUR.CI.wus.glib
S11A.TA (D) Y 120.6 78 259 0.030 0.100 S11A.TA.wus.glib
(V)-velocity (D)-Displacement
Author: www-data
Date: 2015/11/18 23:01:41
mtinv Version 2.1_DEVEL OCT2008
Solution Name: T054.0sec_Z006.0km_
Event ID: mw
Origin ID: 001
Date:
Seismic Moment Tensor Solution
2007/01/24 (024) 12:05:54.00 37.4191 -117.0902 1012422
Depth = 6.0 (km)
Mw = 3.32
Mo = 1.20x10^21 (dyne x cm)
Percent Double Couple = 100 %
Percent CLVD = 0 %
no ISO calculated
Epsilon=-0.00
Percent Variance Reduction = 64.98 %
Total Fit = 47.50
Major Double Couple
strike dip rake
Nodal Plane 1: 178 88 -180
Nodal Plane 2: 88 90 -2
DEVIATORIC MOMENT TENSOR
Moment Tensor Elements: Spherical Coordinates
Mrr= -0.00 Mtt= -0.07 Mff= 0.07
Mrt= -0.04 Mrf= 0.01 Mtf= 1.19 EXP=21
Moment Tensor Elements: Cartesian Coordinates
-0.07 -1.19 -0.04
-1.19 0.07 -0.01
-0.04 -0.01 -0.00
Eigenvalues:
T-axis eigenvalue= 1.20
N-axis eigenvalue= -0.00
P-axis eigenvalue= -1.19
Eigenvalues and eigenvectors of the Major Double Couple:
T-axis ev= 1.20 trend=133 plunge=1
N-axis ev= 0.00 trend=256 plunge=88
P-axis ev=-1.20 trend=43 plunge=2
Maximum Azmuithal Gap=107 Distance to Nearest Station= 91.2 (km)
Number of Stations (D=Displacement/V=Velocity) Used=4 (defining only)
R09A.TA.D S08C.TA.D FUR.CI.D S11A.TA.D
########---------
############-------------
##############-------------
################------------- P -
#################------------- --
##################-------------------
-###################---------------------
####################---------------------
#####################----------------------
#####################----------------------
######################---------------------
######################--------##############
############################################
---------------------#######################
---------------------######################
---------------------######################
--------------------#####################
-------------------#####################
-------------------####################
-----------------############# ###
----------------############# T #
--------------#############
------------#############
---------#########
All Stations defining and nondefining:
Station.Net Def Distance Azi Bazi lo-f hi-f vmodel
(km) (deg) (deg) (Hz) (Hz)
R09A.TA (D) Y 91.2 1 181 0.030 0.100 R09A.TA.wus.glib
S08C.TA (D) Y 95.7 276 95 0.030 0.100 S08C.TA.wus.glib
FUR.CI (D) Y 107.4 169 349 0.030 0.100 FUR.CI.wus.glib
S11A.TA (D) Y 120.6 78 259 0.030 0.100 S11A.TA.wus.glib
(V)-velocity (D)-Displacement
Author: www-data
Date: 2015/11/18 23:01:41
mtinv Version 2.1_DEVEL OCT2008
Solution Name: T055.0sec_Z006.0km_
Event ID: mw
Origin ID: 001
Date:
Seismic Moment Tensor Solution
2007/01/24 (024) 12:05:55.00 37.4191 -117.0902 1012422
Depth = 6.0 (km)
Mw = 3.31
Mo = 1.15x10^21 (dyne x cm)
Percent Double Couple = 97 %
Percent CLVD = 3 %
no ISO calculated
Epsilon=0.02
Percent Variance Reduction = 57.65 %
Total Fit = 13.52
Major Double Couple
strike dip rake
Nodal Plane 1: 271 82 -3
Nodal Plane 2: 2 87 -172
DEVIATORIC MOMENT TENSOR
Moment Tensor Elements: Spherical Coordinates
Mrr= -0.00 Mtt= 0.07 Mff= -0.07
Mrt= 0.06 Mrf= -0.17 Mtf= 1.13 EXP=21
Moment Tensor Elements: Cartesian Coordinates
0.07 -1.13 0.06
-1.13 -0.07 0.17
0.06 0.17 -0.00
Eigenvalues:
T-axis eigenvalue= 1.14
N-axis eigenvalue= 0.02
P-axis eigenvalue= -1.16
Eigenvalues and eigenvectors of the Major Double Couple:
T-axis ev= 1.14 trend=136 plunge=3
N-axis ev= 0.00 trend=24 plunge=81
P-axis ev=-1.14 trend=227 plunge=8
Maximum Azmuithal Gap=107 Distance to Nearest Station= 91.2 (km)
Number of Stations (D=Displacement/V=Velocity) Used=4 (defining only)
R09A.TA.D S08C.TA.D FUR.CI.D S11A.TA.D
##########-------
##############-----------
################-------------
##################---------------
###################----------------
####################-----------------
-#####################-------------------
######################-------------------
#######################--------------------
#######################--------------------
############################---------------
######-#--------------##################---
----------------------######################
----------------------######################
----------------------#####################
----------------------#####################
---------------------####################
-------------------#####################
-------------------####################
---------------############# ###
P ---------------############# T #
--------------#############
------------#############
--------##########
#
All Stations defining and nondefining:
Station.Net Def Distance Azi Bazi lo-f hi-f vmodel
(km) (deg) (deg) (Hz) (Hz)
R09A.TA (D) Y 91.2 1 181 0.030 0.100 R09A.TA.wus.glib
S08C.TA (D) Y 95.7 276 95 0.030 0.100 S08C.TA.wus.glib
FUR.CI (D) Y 107.4 169 349 0.030 0.100 FUR.CI.wus.glib
S11A.TA (D) Y 120.6 78 259 0.030 0.100 S11A.TA.wus.glib
(V)-velocity (D)-Displacement
Author: www-data
Date: 2015/11/18 23:01:40
mtinv Version 2.1_DEVEL OCT2008
Solution Name: T056.0sec_Z004.0km_
Event ID: mw
Origin ID: 001
Date:
Seismic Moment Tensor Solution
2007/01/24 (024) 12:05:56.00 37.4191 -117.0902 1012422
Depth = 4.0 (km)
Mw = 3.22
Mo = 8.37x10^20 (dyne x cm)
Percent Double Couple = 97 %
Percent CLVD = 3 %
no ISO calculated
Epsilon=-0.01
Percent Variance Reduction = 34.06 %
Total Fit = 9.17
Major Double Couple
strike dip rake
Nodal Plane 1: 270 73 -11
Nodal Plane 2: 3 80 -163
DEVIATORIC MOMENT TENSOR
Moment Tensor Elements: Spherical Coordinates
Mrr= -0.95 Mtt= 0.88 Mff= 0.07
Mrt= 1.26 Mrf= -2.33 Mtf= 7.89 EXP=20
Moment Tensor Elements: Cartesian Coordinates
0.88 -7.89 1.26
-7.89 0.07 2.33
1.26 2.33 -0.95
Eigenvalues:
T-axis eigenvalue= 8.43
N-axis eigenvalue= -0.11
P-axis eigenvalue= -8.32
Eigenvalues and eigenvectors of the Major Double Couple:
T-axis ev= 8.43 trend=136 plunge=4
N-axis ev= 0.00 trend=33 plunge=70
P-axis ev=-8.43 trend=227 plunge=19
Maximum Azmuithal Gap=107 Distance to Nearest Station= 91.2 (km)
Number of Stations (D=Displacement/V=Velocity) Used=4 (defining only)
R09A.TA.D S08C.TA.D FUR.CI.D S11A.TA.D
###########------
###############----------
#################------------
###################--------------
#####################--------------
######################---------------
-#######################-----------------
########################-----------------
#########################------------------
################################-----------
###########-------------################---
####--------------------###################
#-----------------------####################
------------------------####################
-----------------------####################
-----------------------####################
----------------------###################
---------------------###################
- -----------------##################
P ----------------############ ###
----------------############ T #
--------------#############
------------#############
-------###########
#
All Stations defining and nondefining:
Station.Net Def Distance Azi Bazi lo-f hi-f vmodel
(km) (deg) (deg) (Hz) (Hz)
R09A.TA (D) Y 91.2 1 181 0.030 0.100 R09A.TA.wus.glib
S08C.TA (D) Y 95.7 276 95 0.030 0.100 S08C.TA.wus.glib
FUR.CI (D) Y 107.4 169 349 0.030 0.100 FUR.CI.wus.glib
S11A.TA (D) Y 120.6 78 259 0.030 0.100 S11A.TA.wus.glib
(V)-velocity (D)-Displacement
Author: www-data
Date: 2015/11/18 23:01:40
mtinv Version 2.1_DEVEL OCT2008
Event ID: mw
Origin ID: 001
Date:
Filename: plotz.jpg
Event ID: mw
Origin ID: 001
Date:
Filename: results.5.jpg
