Event ID: mw
Origin ID: 001
Date:
Filename: gmtmap.jpg
Solution Name: T053.0sec_Z012.0km_
Event ID: mw
Origin ID: 001
Date:
Seismic Moment Tensor Solution
2017/05/06 (126) 10:43:53.00 38.4105 -118.9153 1564572
Depth = 12.0 (km)
Mw = 3.20
Mo = 7.86x10^20 (dyne x cm)
Percent Double Couple = 97 %
Percent CLVD = 3 %
no ISO calculated
Epsilon=0.01
Percent Variance Reduction = 20.37 %
Total Fit = 5.27
Major Double Couple
strike dip rake
Nodal Plane 1: 121 34 96
Nodal Plane 2: 294 56 86
DEVIATORIC MOMENT TENSOR
Moment Tensor Elements: Spherical Coordinates
Mrr= 7.16 Mtt= -5.68 Mff= -1.48
Mrt= -2.91 Mrf= 0.98 Mtf= 3.07 EXP=20
Moment Tensor Elements: Cartesian Coordinates
-5.68 -3.07 -2.91
-3.07 -1.48 -0.98
-2.91 -0.98 7.16
Eigenvalues:
T-axis eigenvalue= 7.80
N-axis eigenvalue= 0.11
P-axis eigenvalue= -7.91
Eigenvalues and eigenvectors of the Major Double Couple:
T-axis ev= 7.80 trend=190 plunge=78
N-axis ev= 0.00 trend=296 plunge=3
P-axis ev=-7.80 trend=27 plunge=11
Maximum Azmuithal Gap=138 Distance to Nearest Station= 40.4 (km)
Number of Stations (D=Displacement/V=Velocity) Used=4 (defining only)
LHV.NN.D WAK.NN.D KVN.NN.D DSP.NN.D
---------------
------------------- P ---
--------------------- -----
---------------------------------
-----------------------------------
#----########------------------------
-#####################-------------------
-#########################---------------
--############################-------------
--###############################----------
---################################--------
---##################################------
----##################################-----
----############# ###################----
-----############ T ####################---
------########### #####################--
-------##################################
--------################################
----------#############################
----------########################-
--------------################---
-----------------------------
------------------------
-----------------
All Stations defining and nondefining:
Station.Net Def Distance Azi Bazi lo-f hi-f vmodel
(km) (deg) (deg) (Hz) (Hz)
LHV.NN (D) Y 40.4 116 296 0.020 0.080 LHV.NN.wus.glib
WAK.NN (D) Y 46.7 282 102 0.020 0.080 WAK.NN.wus.glib
KVN.NN (D) Y 100.2 45 225 0.020 0.080 KVN.NN.wus.glib
DSP.NN (D) Y 142.3 144 325 0.020 0.080 DSP.NN.wus.glib
(V)-velocity (D)-Displacement
Author: www-data
Date: 2017/05/06 14:43:48
mtinv Version 2.1_DEVEL OCT2008
Solution Name: T054.0sec_Z008.0km_
Event ID: mw
Origin ID: 001
Date:
Seismic Moment Tensor Solution
2017/05/06 (126) 10:43:54.00 38.4105 -118.9153 1564572
Depth = 8.0 (km)
Mw = 3.21
Mo = 8.02x10^20 (dyne x cm)
Percent Double Couple = 69 %
Percent CLVD = 31 %
no ISO calculated
Epsilon=0.15
Percent Variance Reduction = 23.17 %
Total Fit = 0.72
Major Double Couple
strike dip rake
Nodal Plane 1: 110 34 85
Nodal Plane 2: 296 56 94
DEVIATORIC MOMENT TENSOR
Moment Tensor Elements: Spherical Coordinates
Mrr= 6.68 Mtt= -6.55 Mff= -0.13
Mrt= -2.59 Mrf= 1.47 Mtf= 3.42 EXP=20
Moment Tensor Elements: Cartesian Coordinates
-6.55 -3.42 -2.59
-3.42 -0.13 -1.47
-2.59 -1.47 6.68
Eigenvalues:
T-axis eigenvalue= 7.27
N-axis eigenvalue= 1.33
P-axis eigenvalue= -8.60
Eigenvalues and eigenvectors of the Major Double Couple:
T-axis ev= 7.27 trend=219 plunge=79
N-axis ev= 0.00 trend=114 plunge=3
P-axis ev=-7.27 trend=24 plunge=11
Maximum Azmuithal Gap=138 Distance to Nearest Station= 40.4 (km)
Number of Stations (D=Displacement/V=Velocity) Used=4 (defining only)
LHV.NN.D WAK.NN.D KVN.NN.D DSP.NN.D
------------- -
----------------- P -----
------------------- -------
---------------------------------
-----------------------------------
---############----------------------
-######################------------------
##########################---------------
-#############################-------------
-################################----------
-##################################--------
--##################################-------
--############## ###################-----
---############# T ####################----
----############ #####################---
-----####################################--
------###################################
-------#################################
---------############################--
----------######################---
---------------##########--------
-----------------------------
------------------------
-----------------
All Stations defining and nondefining:
Station.Net Def Distance Azi Bazi lo-f hi-f vmodel
(km) (deg) (deg) (Hz) (Hz)
LHV.NN (D) Y 40.4 116 296 0.020 0.080 LHV.NN.wus.glib
WAK.NN (D) Y 46.7 282 102 0.020 0.080 WAK.NN.wus.glib
KVN.NN (D) Y 100.2 45 225 0.020 0.080 KVN.NN.wus.glib
DSP.NN (D) Y 142.3 144 325 0.020 0.080 DSP.NN.wus.glib
(V)-velocity (D)-Displacement
Author: www-data
Date: 2017/05/06 14:43:48
mtinv Version 2.1_DEVEL OCT2008
Solution Name: T055.0sec_Z022.0km_
Event ID: mw
Origin ID: 001
Date:
Seismic Moment Tensor Solution
2017/05/06 (126) 10:43:55.00 38.4105 -118.9153 1564572
Depth = 22.0 (km)
Mw = 3.19
Mo = 7.49x10^20 (dyne x cm)
Percent Double Couple = 55 %
Percent CLVD = 45 %
no ISO calculated
Epsilon=0.23
Percent Variance Reduction = 41.84 %
Total Fit = 0.90
Major Double Couple
strike dip rake
Nodal Plane 1: 55 73 5
Nodal Plane 2: 324 86 163
DEVIATORIC MOMENT TENSOR
Moment Tensor Elements: Spherical Coordinates
Mrr= 1.94 Mtt= -7.58 Mff= 5.64
Mrt= -1.29 Mrf= 1.38 Mtf= 2.44 EXP=20
Moment Tensor Elements: Cartesian Coordinates
-7.58 -2.44 -1.29
-2.44 5.64 -1.38
-1.29 -1.38 1.94
Eigenvalues:
T-axis eigenvalue= 6.37
N-axis eigenvalue= 1.87
P-axis eigenvalue= -8.24
Eigenvalues and eigenvectors of the Major Double Couple:
T-axis ev= 6.37 trend=279 plunge=15
N-axis ev= 0.00 trend=130 plunge=73
P-axis ev=-6.37 trend=11 plunge=9
Maximum Azmuithal Gap=138 Distance to Nearest Station= 40.4 (km)
Number of Stations (D=Displacement/V=Velocity) Used=4 (defining only)
LHV.NN.D WAK.NN.D KVN.NN.D DSP.NN.D
---------- P ----
-------------- --------
###--------------------------
#######--------------------------
##########-------------------------
############-----------------------###
-###############--------------------#####
#################------------------######
###################---------------#########
####################------------##########
T #####################---------#############
######################------###############
#########################-##################
############################################
########################-##################
######################----#################
##################---------##############
#############--------------#############
########--------------------###########
---------------------------#########
---------------------------######
--------------------------###
------------------------
-----------------
All Stations defining and nondefining:
Station.Net Def Distance Azi Bazi lo-f hi-f vmodel
(km) (deg) (deg) (Hz) (Hz)
LHV.NN (D) Y 40.4 116 296 0.020 0.080 LHV.NN.wus.glib
WAK.NN (D) Y 46.7 282 102 0.020 0.080 WAK.NN.wus.glib
KVN.NN (D) Y 100.2 45 225 0.020 0.080 KVN.NN.wus.glib
DSP.NN (D) Y 142.3 144 325 0.020 0.080 DSP.NN.wus.glib
(V)-velocity (D)-Displacement
Author: www-data
Date: 2017/05/06 14:43:48
mtinv Version 2.1_DEVEL OCT2008
Solution Name: T056.0sec_Z022.0km_
Event ID: mw
Origin ID: 001
Date:
Seismic Moment Tensor Solution
2017/05/06 (126) 10:43:56.00 38.4105 -118.9153 1564572
Depth = 22.0 (km)
Mw = 3.20
Mo = 7.85x10^20 (dyne x cm)
Percent Double Couple = 99 %
Percent CLVD = 1 %
no ISO calculated
Epsilon=0.01
Percent Variance Reduction = 52.67 %
Total Fit = 22.89
Major Double Couple
strike dip rake
Nodal Plane 1: 53 80 4
Nodal Plane 2: 322 86 170
DEVIATORIC MOMENT TENSOR
Moment Tensor Elements: Spherical Coordinates
Mrr= 0.21 Mtt= -7.57 Mff= 7.35
Mrt= -0.42 Mrf= 1.31 Mtf= 2.01 EXP=20
Moment Tensor Elements: Cartesian Coordinates
-7.57 -2.01 -0.42
-2.01 7.35 -1.31
-0.42 -1.31 0.21
Eigenvalues:
T-axis eigenvalue= 7.83
N-axis eigenvalue= 0.05
P-axis eigenvalue= -7.88
Eigenvalues and eigenvectors of the Major Double Couple:
T-axis ev= 7.83 trend=277 plunge=9
N-axis ev= 0.00 trend=122 plunge=80
P-axis ev=-7.83 trend=8 plunge=4
Maximum Azmuithal Gap=138 Distance to Nearest Station= 40.4 (km)
Number of Stations (D=Displacement/V=Velocity) Used=4 (defining only)
LHV.NN.D WAK.NN.D KVN.NN.D DSP.NN.D
-------- P ------
------------ ----------
##---------------------------
######---------------------------
#########-------------------------##
###########-----------------------####
-##############-------------------#######
################-----------------########
###################-------------###########
###################----------#############
T #####################------################
######################--###################
############################################
############################################
#####################----##################
###################--------################
###############------------##############
###########----------------#############
########---------------------##########
##--------------------------########
----------------------------#####
---------------------------##
------------------------
-----------------
All Stations defining and nondefining:
Station.Net Def Distance Azi Bazi lo-f hi-f vmodel
(km) (deg) (deg) (Hz) (Hz)
LHV.NN (D) Y 40.4 116 296 0.020 0.080 LHV.NN.wus.glib
WAK.NN (D) Y 46.7 282 102 0.020 0.080 WAK.NN.wus.glib
KVN.NN (D) Y 100.2 45 225 0.020 0.080 KVN.NN.wus.glib
DSP.NN (D) Y 142.3 144 325 0.020 0.080 DSP.NN.wus.glib
(V)-velocity (D)-Displacement
Author: www-data
Date: 2017/05/06 14:43:47
mtinv Version 2.1_DEVEL OCT2008
Solution Name: T057.0sec_Z006.0km_
Event ID: mw
Origin ID: 001
Date:
Seismic Moment Tensor Solution
2017/05/06 (126) 10:43:57.00 38.4105 -118.9153 1564572
Depth = 6.0 (km)
Mw = 3.10
Mo = 5.52x10^20 (dyne x cm)
Percent Double Couple = 90 %
Percent CLVD = 10 %
no ISO calculated
Epsilon=-0.05
Percent Variance Reduction = 47.17 %
Total Fit = 4.12
Major Double Couple
strike dip rake
Nodal Plane 1: 327 75 167
Nodal Plane 2: 60 78 15
DEVIATORIC MOMENT TENSOR
Moment Tensor Elements: Spherical Coordinates
Mrr= 0.36 Mtt= -4.79 Mff= 4.43
Mrt= 0.62 Mrf= 1.77 Mtf= 2.36 EXP=20
Moment Tensor Elements: Cartesian Coordinates
-4.79 -2.36 0.62
-2.36 4.43 -1.77
0.62 -1.77 0.36
Eigenvalues:
T-axis eigenvalue= 5.66
N-axis eigenvalue= -0.30
P-axis eigenvalue= -5.36
Eigenvalues and eigenvectors of the Major Double Couple:
T-axis ev= 5.66 trend=284 plunge=19
N-axis ev= 0.00 trend=98 plunge=70
P-axis ev=-5.66 trend=193 plunge=2
Maximum Azmuithal Gap=138 Distance to Nearest Station= 40.4 (km)
Number of Stations (D=Displacement/V=Velocity) Used=4 (defining only)
LHV.NN.D WAK.NN.D KVN.NN.D DSP.NN.D
-----------------
-------------------------
######-----------------------
##########-----------------------
#############----------------------
################---------------------
-##################-------------------###
#####################---------------#####
#####################------------########
T ######################---------##########
########################----##############
###########################-################
############################################
#########################--#################
######################------###############
##################-----------##############
##############---------------############
########---------------------###########
-----------------------------##########
----------------------------########
---------------------------######
--------------------------###
----- ----------------
- P -------------
All Stations defining and nondefining:
Station.Net Def Distance Azi Bazi lo-f hi-f vmodel
(km) (deg) (deg) (Hz) (Hz)
LHV.NN (D) Y 40.4 116 296 0.020 0.080 LHV.NN.wus.glib
WAK.NN (D) Y 46.7 282 102 0.020 0.080 WAK.NN.wus.glib
KVN.NN (D) Y 100.2 45 225 0.020 0.080 KVN.NN.wus.glib
DSP.NN (D) Y 142.3 144 325 0.020 0.080 DSP.NN.wus.glib
(V)-velocity (D)-Displacement
Author: www-data
Date: 2017/05/06 14:43:47
mtinv Version 2.1_DEVEL OCT2008
Solution Name: T058.0sec_Z008.0km_
Event ID: mw
Origin ID: 001
Date:
Seismic Moment Tensor Solution
2017/05/06 (126) 10:43:58.00 38.4105 -118.9153 1564572
Depth = 8.0 (km)
Mw = 3.21
Mo = 8.14x10^20 (dyne x cm)
Percent Double Couple = 96 %
Percent CLVD = 4 %
no ISO calculated
Epsilon=-0.02
Percent Variance Reduction = 60.71 %
Total Fit = 11.57
Major Double Couple
strike dip rake
Nodal Plane 1: 356 42 -106
Nodal Plane 2: 197 50 -76
DEVIATORIC MOMENT TENSOR
Moment Tensor Elements: Spherical Coordinates
Mrr= -7.73 Mtt= -0.33 Mff= 8.06
Mrt= 1.53 Mrf= 0.85 Mtf= 0.95 EXP=20
Moment Tensor Elements: Cartesian Coordinates
-0.33 -0.95 1.53
-0.95 8.06 -0.85
1.53 -0.85 -7.73
Eigenvalues:
T-axis eigenvalue= 8.23
N-axis eigenvalue= -0.17
P-axis eigenvalue= -8.06
Eigenvalues and eigenvectors of the Major Double Couple:
T-axis ev= 8.23 trend=277 plunge=4
N-axis ev= 0.00 trend=8 plunge=11
P-axis ev=-8.23 trend=168 plunge=79
Maximum Azmuithal Gap=138 Distance to Nearest Station= 40.4 (km)
Number of Stations (D=Displacement/V=Velocity) Used=4 (defining only)
LHV.NN.D WAK.NN.D KVN.NN.D DSP.NN.D
##########--######
#########################
###############----##########
###############-------###########
##############-----------###########
##############-------------###########
-#############----------------###########
#############------------------##########
##############------------------###########
############--------------------##########
T ###########---------------------###########
###########---------------------###########
###########----------------------###########
###########-------- -----------###########
###########-------- P -----------##########
###########-------- -----------##########
##########---------------------##########
#########---------------------##########
#########--------------------##########
########------------------##########
########----------------#########
#######-------------#########
######----------#########
###-------########
All Stations defining and nondefining:
Station.Net Def Distance Azi Bazi lo-f hi-f vmodel
(km) (deg) (deg) (Hz) (Hz)
LHV.NN (D) Y 40.4 116 296 0.020 0.080 LHV.NN.wus.glib
WAK.NN (D) Y 46.7 282 102 0.020 0.080 WAK.NN.wus.glib
KVN.NN (D) Y 100.2 45 225 0.020 0.080 KVN.NN.wus.glib
DSP.NN (D) Y 142.3 144 325 0.020 0.080 DSP.NN.wus.glib
(V)-velocity (D)-Displacement
Author: www-data
Date: 2017/05/06 14:43:47
mtinv Version 2.1_DEVEL OCT2008
Solution Name: T059.0sec_Z014.0km_
Event ID: mw
Origin ID: 001
Date:
Seismic Moment Tensor Solution
2017/05/06 (126) 10:43:59.00 38.4105 -118.9153 1564572
Depth = 14.0 (km)
Mw = 3.19
Mo = 7.65x10^20 (dyne x cm)
Percent Double Couple = 92 %
Percent CLVD = 8 %
no ISO calculated
Epsilon=-0.04
Percent Variance Reduction = 57.52 %
Total Fit = 6.52
Major Double Couple
strike dip rake
Nodal Plane 1: 343 46 -116
Nodal Plane 2: 198 49 -66
DEVIATORIC MOMENT TENSOR
Moment Tensor Elements: Spherical Coordinates
Mrr= -6.78 Mtt= -1.00 Mff= 7.79
Mrt= 2.14 Mrf= 0.36 Mtf= 0.14 EXP=20
Moment Tensor Elements: Cartesian Coordinates
-1.00 -0.14 2.14
-0.14 7.79 -0.36
2.14 -0.36 -6.78
Eigenvalues:
T-axis eigenvalue= 7.80
N-axis eigenvalue= -0.30
P-axis eigenvalue= -7.50
Eigenvalues and eigenvectors of the Major Double Couple:
T-axis ev= 7.80 trend=271 plunge=2
N-axis ev= 0.00 trend=2 plunge=18
P-axis ev=-7.80 trend=176 plunge=72
Maximum Azmuithal Gap=138 Distance to Nearest Station= 40.4 (km)
Number of Stations (D=Displacement/V=Velocity) Used=4 (defining only)
LHV.NN.D WAK.NN.D KVN.NN.D DSP.NN.D
######-------#####
#########################
#############################
###############----##############
##############--------##############
##############-----------#############
-#############--------------#############
#############----------------############
##############-----------------############
#############-------------------###########
###########--------------------############
T ##########---------------------############
##########----------------------###########
###########----------------------###########
###########-------- -----------##########
##########--------- P -----------##########
#########--------- -----------#########
#########----------------------#########
#########---------------------#########
########--------------------########
#######-------------------#######
######-----------------######
######-------------######
##------------####
All Stations defining and nondefining:
Station.Net Def Distance Azi Bazi lo-f hi-f vmodel
(km) (deg) (deg) (Hz) (Hz)
LHV.NN (D) Y 40.4 116 296 0.020 0.080 LHV.NN.wus.glib
WAK.NN (D) Y 46.7 282 102 0.020 0.080 WAK.NN.wus.glib
KVN.NN (D) Y 100.2 45 225 0.020 0.080 KVN.NN.wus.glib
DSP.NN (D) Y 142.3 144 325 0.020 0.080 DSP.NN.wus.glib
(V)-velocity (D)-Displacement
Author: www-data
Date: 2017/05/06 14:43:47
mtinv Version 2.1_DEVEL OCT2008
Event ID: mw
Origin ID: 001
Date:
Filename: plotz.jpg
Event ID: mw
Origin ID: 001
Date:
Filename: results.5.jpg
